PTFE Coated fiberfglass fabric

Product Performance

1.Stable dimension, high intensity, elongation coefficient less 5%.

2.Good temperature resistance, 24 hours working temperature -70～260℃.

3.Low coefficient of friction and dielectric constant, high insulation property.

4.Non-stick, easy to clean stains and adhesive on the surface.

5.Good chemical resistance, it can resist almost all of chemical, acids, alkalis, and salt, it is fireproof, ageing resistance.kness and widths.

Product Application

1.Used as various of liners to resist high temperature, such as microwave liner, oven liner, or other liners.

2.Used as non-stick liners, intermediate.

3.Used as various conveyor belts, fusing belts, sealing belts or anywhere need resisting high temperature, non-stick, chemical resistant etc.

4.Used as covering or wrapping material in petroleum, chemical industries, as wrapping material, insulating material, high temperature resistance material in electrical industries, desulfurizing material in power plant etc.

Product parameters：

em No	Color	Thickness(mm±5%	Base fabricweigl(gm)	Toal welth(g/m)	Tensile Strengti(N/5cm)		Tear Resistencr(N/5cm)
em No	Color	Thickness(mm±5%	Base fabricweigl(gm)	Toal welth(g/m)	Wap	Wef	Wam	Weft
9008AJ	Brown	0.075	48	150	650	550	8	8
9008J	Whte	0.075	48	150	600	500	6	6
9008BJ	Black	0.075	48	150	600	500	6	6
9010J	White	0.095	105	180	850	750	7	7
9011AJ	Rrown	0.105	105	190	1000	900	10	10
9012AJ	Rrow	0.115	105	220	1150	1000	12	12
9013AJ	Brown	0.125	105	250	1200	1100	15	15
9013BJ	Black	0.125	105	250	1050	850	12	12
9013J	Whte	0.125	105	250	950	850	12	12
9015AJ	Brown	0.14	105	300	1350	1250	18	18
9015BJ	Black	0.14	105	290	1300	1200	16	16
9018AJ	Browr	17	165	350	1750	1550	20	20
9018BJ	Rlack	0.17	165	350	1500	1300	15	15
9020AJ	Brown	0.2	165	425	1800	1600	20	20
9020BJ	Black	0.19	210	360	2000	1700	22	22
9025AJ	Rrown	0.235	210	490	2200	1750	25	25
9025BJ	Black	0.23	210	480	2000	1700	25	25
9025J	White	0.235	210	490	1800	1500	20	20
9030AJ	Rrown	0.28	255	590	240	1700	35	30
9030BJ	Rlack	28	255	580	2400	1700	35	30
9035AJ	Rrown	0.32	255	630	2600	2000	40	35
9035BJ	Black	0.32	255	630	2600	2000	40	35
9036AJ	Brown	0.35	305	680	3200	2200	45	40
9036BJ	Black	0.36	305	730	3200	2200	45	40
9040AJ	Browr	0.38	350	780	3200	2100	45	40
9040BJ	Rlack	0.38	350	780	3000	2000	45	40
9055AJ	Brown	0.52	538	1050	3500	3000	100	80
9055J	Whte	0.52	538	1050	3200	2800	80	60
9055BJ	Rlack	0.52	538	1050	3500	300	100	80
9060BJ	Black	0.58	538	1150	3800	3300	120	100
9065A	Rrowr	63	578	1200	4000	350	140	120
9065BJ	Black	0.63	578	1200	4000	3200	140	120
9065J	White	0.63	578	1200	3800	3200	120	100
9075AJ	Rrown	0.73	655	1400	4200	3800	180	160
9080AJ	Brown	0.78	740	1500	4500	4000	220	180
9080BJ	Black	0.73	665	1400	4200	380	220	180
9080J	Whte	0.73	665	1400	4000	3500	180	150
9090AJ	Browr	0.98	865	1850	5500	4500	250	200
9090BJ	Rlack	0.98	865	1850	5500	4500	250	200
9100AJ	Brown	0.98	910	1250	6000	5000	300	250

We use best imported fiberglass as the weaving material to plain knit or specially knit into superior fiberglass basic cloth, coat it with fine PTFE resin then make it into various PTFE high temperature resistance cloth in different thickness and widths.

For more information, please contact our online customer service
